| Type | KBL cable entry system |
| Model | KBL-QVT50/4 |
| Number of cores | 4 |
| Thread specification | M50x1.5 |
| Packing Unit | 10 |
| Number of modules | Small module x4 20*20 (maximum diameter 16mm, applicable module specification KTs16 or below) |
| Material | Polycarbonate |
| color | Grey |
| Flame retardant grade | UL 94 V-0, self-extinguishing |
| Protection level | IP54, use sealing gasket and select the correct core specification |
| Temperature range | -30°C to +100°C (static) |
| Characteristic | Halogen-free, Silicone-free |
| Thread length | 14 mm |
