M12 interface、IO-Link Hub、NPN、16DI、expandable  module、00B933

M12 interface、IO-Link Hub、NPN、16DI、expandable module、00B933

Ordering code: 00B933
Part number : FNI IOL-332-004-M12
  • 针脚PNJ - 2.png
  • IO-Link device
  • 8 ports and 16 signals
  • Scalable devices
  • Protection level: IP 67 (when correctly connected)
Collect Inquiry

Related recommendations

  • Function Parameter
  • Resource Download
  • Related Video
IO-LinkDevice
IllustrateExtension module
Type16×DI NPN
Rated working voltage UB18...30 V
IO-Link RUN function indicatorGreen LED indicator light
Power start-up indication lightGreen LED indicator light
Connection: IO-Link M12,A-coded,Male/D-coded,Female
Connection: I/O portM12,A-coded,Female
Connection: USVia IO-Link interface
Connection: UAVia IO-Link interface
Number of I/O ports8
Input quantityMaximum 16
Output quantity-
Configurable/parameterizedNo
Single channel monitoringNo
Codable via IO-LinkNo
Maximum load current, sensor350 mA
Maximum load current, actuator-
Port status indicatorYellow/Red LED
Total current UT< 1.4A
Total current UO< 1.4A
Degree of protection as per IEC 60529IP67(When connected correctly)
Operating temperature-25...+70 ℃
Storage temperature-25...+85 °C
Weight-
Fastener2 pcs mounting hole
Dimensions (length × width × height)143×58×28.7 mm
Shell materialModified plastic
RemarkRecommended to be used together  with 64DD21-xxx
lO-Link 1.1
Max. cycle time5 ms
IO-Link tackled data length4 pcs input bytes
Indicator light communicationGreen LED indicator light
Indicator light errorRed LED indicator light
